0191210007

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description Ring Tongue Terminal 18-22AWG 19.8mm 7.6mm Tin InsulKrimp? Bag
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.3784
≥1 USD $0.3784
≥10 USD $0.3036
≥100 USD $0.222728
≥500 USD $0.177162
≥1000 USD $0.161973
Inventory: 1685
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Length - Ring Center to Termination 0.207 5.26mm
Width - Outer Edges 0.301 7.65mm
Length - Overall 0.781 19.84mm
Length - Termination 0.400 10.16mm

Technical

Tongue Inside Opening 0.173 (4.39mm)
Stud/Tab Size 8 Stud
Wire Cross Section 1.5 mm2
Terminal Type Flanged
Insulation Insulated
Insulation Diameter 0.145 (3.68mm)
Terminal and Terminal Block Type FORK TERMINAL
Wire Gauge 18-22 AWG
Contact Finish Electro-Tin
HTS Code 8536.90.40.00
Color Red
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series InsulKrimp
Packaging Bulk

Physical

Material - Insulation Poly-Vinyl Chloride (PVC)
Mounting Type Free Hanging (In-Line)
Contact Material Copper

Supply Chain

Factory Lead Time 8 Weeks
