0190990016
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
Snap Spade Tongue Terminal 18-22AWG 23.34mm 8.38mm Electro-Tin InsulKrimp? Adhesive T/R
PDF
/
Buying Options
Total Price: USD $0.39
Unit Price: USD $0.3872
≥1 USD $0.3872
≥10 USD $0.33
≥100 USD $0.256784
Inventory: 37043
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Ring Center to Termination 0.261 6.63mm
Width - Outer Edges 0.330 8.38mm
Length - Overall 0.919 23.34mm
Length - Termination 0.405 10.29mm
Technical
Tongue Inside Opening 0.156 (3.96mm)
Stud/Tab Size 10 Stud
Wire Cross Section 1.5 mm2
Terminal Type Spring, Snap
Insulation Insulated
Insulation Diameter 0.145 (3.68mm)
Terminal and Terminal Block Type FORK TERMINAL
Wire Gauge 18-22 AWG
Contact Finish Electro-Tin
HTS Code 8536.90.40.00
Color Red
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series InsulKrimp
Packaging Tape & Reel (TR)
Physical
Material - Insulation Poly-Vinyl Chloride (PVC)
Mounting Type Free Hanging (In-Line)
Contact Material Copper
Supply Chain
Factory Lead Time 6 Weeks
