0190990007
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
InsulKrimp ROHS3Compliant Insulated Electro-Tin Spade Terminal Connector 0.145 (3.68mm)
PDF
/
Inventory: 4173
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mounting Type Free Hanging (In-Line)
Material - Insulation Poly-Vinyl Chloride (PVC)
Technical
Packaging Bulk
Series InsulKrimp
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Color Red
HTS Code 8536.90.40.00
Contact Finish Electro-Tin
Wire Gauge 18-22 AWG
Terminal and Terminal Block Type FORK TERMINAL
Insulation Diameter 0.145 (3.68mm)
Insulation Insulated
Terminal Type Spring, Snap
Wire Cross Section 0.8 mm2
Stud/Tab Size 5 Stud
Tongue Inside Opening 0.105 (2.67mm)
Dimensions
Length - Termination 0.405 10.29mm
Length - Overall 0.810 20.57mm
Width - Outer Edges 0.250 6.35mm
Length - Ring Center to Termination 0.230 5.84mm
Compliance
RoHS Status ROHS3 Compliant
