8264
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
CONN SPADE TERM 18-22AWG #8 RED
PDF
/
Buying Options
Total Price: USD $347.54
Unit Price: USD $347.5384
≥1 USD $347.5384
Inventory: 96
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Material Copper, ETP
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material Copper
Material - Insulation Vinyl
Technical
Packaging Bulk
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Color Red
HTS Code 8536.90.40.00
Orientation Straight
Contact Finish Tin
Wire Gauge 18-22 AWG
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 18 AWG
Terminal and Terminal Block Type FORK TERMINAL
Insulation Diameter 0.145 (3.68mm)
Insulation Insulated
Terminal Type Spring, Snap
Stud/Tab Size 8 Stud
Dimensions
Length 17.78mm
Length - Termination 0.450 11.43mm
Length - Overall 0.700 17.78mm
Width - Outer Edges 0.300 7.62mm
Length - Ring Center to Termination 0.250 6.35mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
