RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description CONN SPADE TERM 14-16AWG #6
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Contact Material Copper, ETP
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material Copper

Technical

Packaging Bulk
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
HTS Code 8536.90.40.00
Orientation Straight
Contact Finish Tin
Wire Gauge 14-16 AWG
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 14 AWG
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Spring, Snap
Stud/Tab Size 6 Stud

Dimensions

Length 17.272mm
Length - Termination 0.250 6.35mm
Length - Overall 0.680 17.27mm
Width - Outer Edges 0.250 6.35mm
Length - Ring Center to Termination 0.250 6.35mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
