8253
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
CONN SPADE TERM 10-12AWG #10 YEL
PDF
/
Buying Options
Total Price: USD $2.77
Unit Price: USD $2.76545
≥1 USD $2.76545
≥10 USD $2.26955
≥100 USD $2.1983
≥500 USD $2.12705
≥1000 USD $2.05675
Inventory: 1890
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Material Copper, ETP
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material Copper
Material - Insulation Vinyl
Technical
Packaging Bulk
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Color Yellow
HTS Code 8536.90.40.00
Contact Finish Tin
Wire Gauge 10-12 AWG
Wire Gauge (Max) 12 AWG
Wire Gauge (Min) 10 AWG
Terminal and Terminal Block Type FORK TERMINAL
Insulation Diameter 0.255 (6.48mm)
Insulation Insulated
Terminal Type Flanged
Stud/Tab Size 10 Stud
Dimensions
Length 21.336mm
Width 8.13mm
Length - Termination 0.550 13.97mm
Length - Overall 0.840 21.34mm
Diameter - Inside 6.35 mm
Width - Outer Edges 0.320 8.13mm
Length - Ring Center to Termination 0.290 7.37mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
