8251
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
Terminals Insul Flanged Spade terminal 1.03x.144
PDF
/
Inventory: 1172
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status Non-RoHS Compliant
Dimensions
Length - Ring Center to Termination 0.290 7.37mm
Width - Outer Edges 0.320 8.13mm
Diameter - Inside 6.35 mm
Length - Overall 0.840 21.34mm
Length - Termination 0.550 13.97mm
Width 8.13mm
Length 21.336mm
Technical
Stud/Tab Size 6 Stud
Terminal Type Flanged
Insulation Insulated
Insulation Diameter 0.255 (6.48mm)
Terminal and Terminal Block Type FORK TERMINAL
Wire Gauge (Min) 10 AWG
Wire Gauge (Max) 12 AWG
Wire Gauge 10-12 AWG
Contact Finish Tin
HTS Code 8536.90.40.00
Color Yellow
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Bulk
Physical
Material - Insulation Vinyl
Material Copper
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper, ETP
Supply Chain
Factory Lead Time 6 Weeks
