8249
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
CONN SPADE TERM 14-16AWG #8 BLU
PDF
/
Buying Options
Total Price: USD $4.44
Unit Price: USD $4.444115
≥1 USD $4.444115
≥10 USD $4.192554
≥100 USD $3.955245
≥500 USD $3.731361
≥1000 USD $3.520153
Inventory: 1195
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Material Copper, ETP
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material Copper
Material - Insulation Vinyl
Technical
Packaging Bulk
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Color Blue
HTS Code 8536.90.40.00
Contact Finish Tin
Wire Gauge 14-16 AWG
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 14 AWG
Terminal and Terminal Block Type FORK TERMINAL
Insulation Diameter 0.175 (4.45mm)
Insulation Insulated
Terminal Type Flanged
Stud/Tab Size 8 Stud
Dimensions
Length 17.78mm
Width 7.62mm
Length - Termination 0.450 11.43mm
Length - Overall 0.700 17.78mm
Diameter - Inside 4.32 mm
Width - Outer Edges 0.300 7.62mm
Length - Ring Center to Termination 0.250 6.35mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
