8225
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
CONN SPADE TERM 10-12AWG #8
PDF
/
Buying Options
Total Price: USD $8.89
Unit Price: USD $8.888
≥1 USD $8.888
≥10 USD $7.1104
≥100 USD $5.68832
≥500 USD $4.97728
Inventory: 214
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Material Copper, ETP
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material Copper
Technical
Packaging Bulk
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
HTS Code 8536.90.40.00
Contact Finish Tin
Wire Gauge 10-12 AWG
Wire Gauge (Max) 12 AWG
Wire Gauge (Min) 10 AWG
Terminal and Terminal Block Type FORK TERMINAL
Insulation Non-Insulated
Terminal Type Standard
Stud/Tab Size 8 Stud
Dimensions
Length 18.542mm
Width 8.13mm
Length - Termination 0.250 6.35mm
Length - Overall 0.730 18.54mm
Diameter - Inside 3.43 mm
Width - Outer Edges 0.320 8.13mm
Length - Ring Center to Termination 0.290 7.37mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
