8220
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
ROHS3Compliant Lead Free Non-Insulated Tin Spade Terminal Connector 18AWG 1.78mm
PDF
/
Buying Options
Total Price: USD $131.74
Unit Price: USD $131.736
≥1 USD $131.736
Inventory: 50
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length - Ring Center to Termination 0.250 6.35mm
Width - Outer Edges 0.300 7.62mm
Diameter - Inside 1.78 mm
Length - Overall 0.650 16.50mm
Length - Termination 0.250 6.35mm
Width 7.62mm
Length 16.51mm
Technical
Stud/Tab Size 10 Stud
Terminal Type Standard
Insulation Non-Insulated
Terminal and Terminal Block Type FORK TERMINAL
Wire Gauge (Min) 22 AWG
Wire Gauge (Max) 18 AWG
Wire Gauge 18-22 AWG
Contact Finish Tin
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Bulk
Physical
Material Copper
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper, ETP
Supply Chain
Factory Lead Time 6 Weeks
