MU10-8FFBK
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
CONN SPADE TERM 10-12AWG #8
PDF
/
Inventory: 2438
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Copper, ETP
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Weight 644.101165g
Body Material Copper
Technical
Packaging Bulk
Published 2000
Series Scotchlok?
Feature Butted Seam
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Depth 8.12mm
Contact Finish Tin
Wire Gauge 10-12 AWG
Wire Gauge (Max) 12 AWG
Wire Gauge (Min) 10 AWG
Body Plating Tin
Insulation Non-Insulated
Terminal Type Flanged
Stud/Tab Size 8 Stud
Dimensions
Length 18.542mm
Length - Termination 0.250 6.35mm
Length - Overall 0.730 18.54mm
Width - Outer Edges 0.320 8.13mm
Length - Ring Center to Termination 0.290 7.37mm
Compliance
RoHS Status RoHS Compliant
