MNG14-10FLK
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
Fork Terminal 14-16AWG 22.6mm 8.12mm Case
PDF
/
Buying Options
Total Price: USD $0.43
Unit Price: USD $0.429318
≥1 USD $0.429318
Inventory: 6819
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Copper, ETP
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Weight 1.21336kg
Material - Insulation Polyamide (PA), Nylon
Technical
Packaging Bulk
Published 2000
Series Scotchlok?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Color Blue
Depth 8.12mm
Contact Finish Tin
Wire Gauge 14-16 AWG
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 14 AWG
Insulation Diameter 0.170 (4.32mm)
Insulation Insulated
Terminal Type Spring, Snap
Stud/Tab Size 10 Stud
Dimensions
Length 22.606mm
Length - Termination 0.460 11.68mm
Length - Overall 0.890 22.61mm
Width - Outer Edges 0.320 8.13mm
Length - Ring Center to Termination 0.250 6.35mm
Compliance
RoHS Status RoHS Compliant
