MNG10-14FLX-BOTTLE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
Terminal Spade Connector
PDF
/
Buying Options
Total Price: USD $148.04
Unit Price: USD $148.042604
≥1 USD $148.042604
≥200 USD $59.069997
≥500 USD $57.096708
≥1000 USD $56.121223
Inventory: 9750
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length - Ring Center to Termination 0.440 11.18mm
Width - Outer Edges 0.430 10.92mm
Length - Overall 1.240 31.50mm
Length - Termination 0.550 13.97mm
Technical
Stud/Tab Size 1/4 Stud
Terminal Type Spring, Snap
Insulation Insulated
Insulation Diameter 0.250 (6.35mm)
Wire Gauge 10-12 AWG
Contact Finish Tin
Color Yellow
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Scotchlok?
Published 2002
Packaging Bulk
Physical
Material - Insulation Polyamide (PA), Nylon
Mounting Type Free Hanging (In-Line)
Contact Material Copper, ETP
Supply Chain
Factory Lead Time 3 Weeks
