LFV14-6Q
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
3M LFV series Insulated Crimp Spade Connector, 16AWG to 14AWG, #6 Stud Size, Blue Vinyl
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.6688
≥1 USD $0.6688
≥10 USD $0.58256
≥100 USD $0.532576
≥500 USD $0.501248
≥1000 USD $0.480304
≥3000 USD $0.438557
Inventory: 305
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Copper, ETP
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Weight 317.514659g
Material - Insulation Vinyl
Technical
Packaging Bulk
Series Highland?
Feature Butted Seam
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Color Blue
Gender Female
Orientation Straight
Contact Finish Tin
Wire Gauge 14-16 AWG
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 14 AWG
Wire/Cable Gauge -14 AWG
Insulation Diameter 0.170 (4.32mm)
Insulation Insulated
Terminal Type Spring, Snap
Stud/Tab Size 6 Stud
Stud Size M3.5
Dimensions
Height 114.3mm
Length 22.352mm
Width 6.35mm
Thickness 760μm
Length - Termination 0.450 11.43mm
Length - Overall 0.880 22.35mm
Width - Outer Edges 0.250 6.35mm
Length - Ring Center to Termination 0.250 6.35mm
Compliance
RoHS Status Non-RoHS Compliant
