BS-22-10-NB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
CONN SPADE TERM 14-16AWG #10 BLU
PDF
/
Inventory: 2180
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Copper, ETP
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Weight 1.088622g
Material - Insulation Polyamide (PA), Nylon
Technical
Packaging Bulk
Published 2001
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Color Blue
Contact Finish Tin
Wire Gauge 14-16 AWG
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 14 AWG
Insulation Diameter 0.170 (4.32mm)
Insulation Insulated
Terminal Type Flanged
Stud/Tab Size 10 Stud
Dimensions
Length 21.844mm
Length - Termination 0.460 11.68mm
Length - Overall 0.860 21.84mm
Width - Outer Edges 0.300 7.62mm
Length - Ring Center to Termination 0.250 6.35mm
Compliance
RoHS Status ROHS3 Compliant
