94864
RoHS
RoHS compliant
RoHS compliantPackage 100
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
CONN SPADE TERM 18-22AWG #6 RED
PDF
/
Buying Options
Total Price: USD $0.48
Unit Price: USD $0.4752
≥1 USD $0.4752
≥10 USD $0.41272
≥100 USD $0.376992
≥500 USD $0.354816
≥1000 USD $0.340032
≥3000 USD $0.310438
Inventory: 614
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Copper, ETP
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Package / Case 100
Weight 1.043262kg
Material - Insulation Polyamide (PA), Nylon
Technical
Packaging Bulk
Published 2002
Series Highland?
Feature Butted Seam
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Color Red
Orientation Straight
Contact Finish Tin
Wire Gauge 18-22 AWG
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 18 AWG
Insulation Diameter 0.145 (3.68mm)
Insulation Insulated
Terminal Type Spring, Snap
Stud/Tab Size 6 Stud
Dimensions
Length 22.098mm
Width 6.35mm
Length - Termination 0.440 11.18mm
Length - Overall 0.870 22.10mm
Width - Outer Edges 0.250 6.35mm
Length - Ring Center to Termination 0.250 6.35mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
