32-10
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
CONN SPADE TERM 14-16AWG #10
PDF
/
Inventory: 9420
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length - Termination 0.125 inch
Plating Thickness 10μin
Technical
Stud/Tab Size 10 Stud
Terminal Type Standard
Insulation Non-Insulated
Insulator Color BLACK
Contact Pattern RECTANGULAR
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 16 AWG
Dielectric Withstanding Voltage 1500VAC V
Body/Shell Style PLUG
Mating Contact Pitch 0.1 inch
Wire Gauge 14-16 AWG
Contact Style SQ PIN-SKT
Rated Current (Signal) 1A
Body Depth 0.325 inch
Operating Temperature (Min) -40°C
Contact Gender FEMALE
Body Breadth 0.1 inch
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 1
Body Length or Diameter 3.2 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Total Number of Contacts 32
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 1
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Bulk
Physical
Weight 725.747792mg
Insulation Material GLASS FILLED POLYESTER
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 3 Weeks
