880642-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Terminals RING TONGUE
PDF
/
Buying Options
Total Price: USD $0.07
Unit Price: USD $0.071465
≥1 USD $0.071465
Inventory: 57
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Contact Material Brass
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Tape & Reel (TR)
Published 2008
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
HTS Code 8536.90.40.00
Depth 8.1mm
Wire Gauge 13-17 AWG
ELV Compliant
Wire Gauge (Max) 17 AWG
Wire Gauge (Min) 13 AWG
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Diameter 0.106 ~ 0.157 (2.69mm ~ 3.99mm)
Insulation Non-Insulated
Terminal Type Circular
Insulated Wire Support Yes
Heavy Duty No
Terminal Gender FEMALE
Stud Diameter 4.3 mm
Number of Holes 2
Dimensions
Length 19.8mm
Thickness 0.024 0.61mm
Length - Overall 0.780 19.81mm
Diameter - Inside 1.82 mm
Width - Outer Edges 0.319 8.10mm
Material Thickness 609.6μm
Tongue Thickness 600μm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Not Applicable
