8-53418-1
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Terminals TERMINAL,PIDG PVF2 R 16-14 10
PDF
/
Buying Options
Total Price: USD $1.29
Unit Price: USD $1.2936
≥1 USD $1.2936
≥10 USD $1.18096
≥100 USD $1.053096
≥500 USD $0.843638
≥1000 USD $0.75636
≥3000 USD $0.720069
Inventory: 1134
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status Non-RoHS Compliant
Dimensions
Tongue Thickness 840μm
Width - Outer Edges 0.312 7.92mm
Diameter - Inside 3.88 mm
Length - Overall 0.844 21.44mm
Thickness 0.031 0.79mm
Plating Thickness 2.54μm
Length 21.4376mm
Technical
Number of Holes 1
Stud Diameter 5 mm
Heavy Duty No
Insulated Wire Support Yes
Stud/Tab Size 10 Stud
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.105 ~ 0.150 (2.67mm ~ 3.81mm)
Terminal and Terminal Block Type RING TERMINAL
Plating Lead, Tin
ELV Non-Compliant
Wire Gauge 14-16 AWG
Contact Finish Tin-Lead
HTS Code 8536.90.40.00
Color Natural, Blue Stripe
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Feature Radiation Resistant, Serrated Termination
Series PIDG
Published 2008
Packaging Bulk
Physical
Material - Insulation Polyvinylidene Fluoride (PVDF)
Mounting Type Free Hanging (In-Line)
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 21 Weeks
