8-34141-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 16-22AWG #4 CRIMP
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.5368
≥1 USD $0.5368
≥10 USD $0.52008
≥100 USD $0.419408
≥500 USD $0.325486
≥1000 USD $0.283985
≥3000 USD $0.270362
Inventory: 516
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material - Insulation Poly-Vinyl Chloride (PVC)
Technical
Packaging Bulk
Published 2009
Series Plasti-Grip
Feature Serrated Termination
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Color Red
Gender Female
HTS Code 8536.90.40.00
Orientation Straight
Contact Finish Tin
Voltage - Rated AC 600V
Wire Gauge 16-22 AWG
ELV Compliant
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 16 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.105 ~ 0.140 (2.67mm ~ 3.56mm)
Insulation Insulated
Terminal Type Circular
Wire/Cable Diameter 3.56 mm
Stud/Tab Size 4 Stud
Insulated Wire Support Yes
Heavy Duty No
Stud Diameter 3.0226 mm
Number of Holes 1
Stud Size M2.5
Dimensions
Length 17.37mm
Thickness 0.031 0.79mm
Length - Overall 0.684 17.37mm
Width - Outer Edges 0.218 5.54mm
Tongue Thickness 840μm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
