696423-4 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description CONN RING CIRC 14-16AWG #6 CRIMP
PDF
/
Buying Options
Total Price: USD $0.57
Unit Price: USD $0.572
≥1 USD $0.572
≥10 USD $0.54472
≥100 USD $0.52096
≥500 USD $0.513744
≥1000 USD $0.448888
≥3000 USD $0.432115
Inventory: 3051
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 18 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)

Physical

Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material - Insulation Polyvinylidene Fluoride (PVDF)

Technical

Packaging Bulk
Published 2004
Series PIDG
Feature Radiation Resistant, Serrated Termination
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Color Natural, Blue Stripe
Gender Female
HTS Code 8536.90.40.00
Orientation Straight
Depth 7.92mm
Wire Gauge 14-16 AWG
ELV Compliant
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 14 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.105 ~ 0.150 (2.67mm ~ 3.81mm)
Insulation Insulated
Terminal Type Circular
Wire/Cable Diameter 3.81 mm
Wire Cross Section 2.62 mm2
Stud/Tab Size 6 Stud
Insulated Wire Support Yes
Heavy Duty No
Stud Diameter 3.683 mm
Number of Holes 1
Stud Size M3.5

Dimensions

Length 21.5646mm
Thickness 0.031 0.79mm
Length - Overall 0.849 21.56mm
Diameter - Inside 3.8862 mm
Width - Outer Edges 0.312 7.92mm
Material Thickness 787.4μm
Tongue Thickness 790μm

Compliance

REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Not Applicable
