696422-3 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description CONN RING CIRC 16-22AWG #6 CRIMP
PDF
/
Buying Options
Total Price: USD $0.78
Unit Price: USD $0.7832
≥1 USD $0.7832
≥10 USD $0.74272
≥100 USD $0.709984
≥500 USD $0.700304
≥1000 USD $0.611952
≥3000 USD $0.589072
Inventory: 10073
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Not Applicable
RoHS Status RoHS Compliant
REACH SVHC Unknown

Dimensions

Tongue Thickness 790μm
Material Thickness 787.4μm
Width - Outer Edges 0.218 5.54mm
Diameter - Inside 3.2512 mm
Length - Overall 0.677 17.20mm
Thickness 0.031 0.79mm
Length 17.1958mm

Technical

Stud Size M3.5
Number of Holes 1
Stud Diameter 3.683 mm
Heavy Duty No
Insulated Wire Support Yes
Stud/Tab Size 6 Stud
Wire/Cable Diameter 3.175 mm
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.080 ~ 0.125 (2.03mm ~ 3.18mm)
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 16 AWG
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 22 AWG
ELV Compliant
Wire Gauge 16-22 AWG
Contact Finish Tin
Orientation Straight
HTS Code 8536.90.40.00
Gender Female
Color Natural, Red Stripe
Min Operating Temperature -40°C
Max Operating Temperature 150°C
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Radiation Resistant, Serrated Termination
Series PIDG
Published 2007
Packaging Bulk

Physical

Material - Insulation Polyvinylidene Fluoride (PVDF)
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 18 Weeks
