696049-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 8AWG #8 CRIMP
PDF
/
Buying Options
Total Price: USD $1.64
Unit Price: USD $1.6368
≥1 USD $1.6368
≥10 USD $1.5004
≥100 USD $1.455872
≥500 USD $1.440912
≥1000 USD $1.337512
≥3000 USD $1.315318
Inventory: 3122
Minimum: 1
-
+
Technical Details
Technical
HTS Code 8536.90.40.00
Depth 10.31mm
Voltage - Rated AC 600V
Wire Gauge 8 AWG
ELV Compliant
Wire/Cable Gauge 8 AWG
Sealable No
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 9.14 mm
Insulation Insulated
Terminal Type Circular
Stud/Tab Size 8 Stud
Heavy Duty Yes
Stud Diameter 4.34 mm
Number of Holes 1
Stud Size M4
Color Red
Resistance 8Ohm
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Serrated Termination
Series Plasti-Grip
Published 2008
Packaging Tape & Reel (TR)
Dimensions
Length 35.306mm
Thickness 0.048 1.22mm
Length - Overall 1.390 35.31mm
Width - Outer Edges 0.406 10.31mm
Material Thickness 1.22mm
Tongue Thickness 1.22mm
Compliance
RoHS Status RoHS Compliant
Lead Free Not Applicable
Physical
Material - Insulation Poly-Vinyl Chloride (PVC)
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 15 Weeks
