626036-3 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description Terminal Ring Connector
PDF
/
Inventory: 1536
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 week ago)

Physical

Contact Material Brass
Mounting Type Free Hanging (In-Line)

Technical

Packaging Reel
Published 2011
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp
ECCN Code EAR99
HTS Code 8536.90.40.00
Contact Finish Tin
Wire Gauge 10-11 AWG
ELV Compliant
Plating Unplated
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.126 ~ 0.209 (3.20mm ~ 5.31mm)
Insulation Non-Insulated
Terminal Type Circular
Wire Cross Section 6 mm2
Insulated Wire Support Yes
Heavy Duty No
Stud Diameter 5.3 mm
Number of Holes 1

Dimensions

Length 19mm
Thickness 0.032 0.81mm
Length - Overall 0.748 19.00mm
Diameter - Inside 2.92 mm
Width - Outer Edges 0.374 9.50mm
Material Thickness 800μm
Tongue Thickness 800μm

Compliance

RoHS Status RoHS Compliant
Lead Free Not Applicable
