61424-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Terminals LSG-3CG1-1
PDF
/
Inventory: 5804
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Material Brass
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Underplate Material Nickel
Technical
Packaging Tape & Reel (TR)
Published 1998
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
HTS Code 8536.90.40.00
Contact Finish Tin
Wire Gauge 10-12 AWG
ELV Compliant
Wire Gauge (Max) 12 AWG
Wire Gauge (Min) 10 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.170 ~ 0.210 (4.32mm ~ 5.33mm)
Insulation Non-Insulated
Terminal Type Circular
Wire/Cable Diameter 5.33 mm
Wire Cross Section 6 mm2
Insulated Wire Support Yes
Heavy Duty No
Stud Diameter 3.68 mm
Number of Holes 1
Stud Size M3.5
Dimensions
Length 23.348366mm
Thickness 0.040 1.02mm
Length - Overall 0.921 23.39mm
Diameter - Inside 2.54 mm
Width - Outer Edges 0.343 8.71mm
Material Thickness 1.016mm
Tongue Thickness 1.00838mm
Compliance
RoHS Status RoHS Compliant
Lead Free Not Applicable
