55852-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Terminals 16-14 PRE-INSUL SEALED TERM R
PDF
/
Buying Options
Total Price: USD $1.94
Unit Price: USD $1.936
≥1 USD $1.936
≥10 USD $1.72744
≥100 USD $1.560856
≥500 USD $1.262721
≥1000 USD $1.113649
Inventory: 1012
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Tongue Thickness 863.6μm
Material Thickness 810μm
Width - Outer Edges 0.310 7.87mm
Diameter - Inside 2.03 mm
Length - Overall 1.218 30.94mm
Thickness 0.032 0.81mm
Length 28.65mm
Technical
Number of Holes 1
Government Qualified No
Stud Diameter 4.82 mm
Terminal Gender FEMALE
Heavy Duty Yes
Stud/Tab Size 10 Stud
Wire Cross Section 2.62 mm2
Terminal Type Circular
Insulation Insulated with Heat Shrink
Insulation Diameter 0.190 (4.83mm)
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 14 AWG
ELV Compliant
Wire Gauge 14-16 AWG
HTS Code 8536.90.40.00
Color Blue
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2009
Packaging Bulk
Physical
Body Material Copper
Material - Insulation Polyolefin
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper, ETP
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 7 Weeks
