54741-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Terminal Ring Connector
PDF
/
Buying Options
Total Price: USD $1.31
Unit Price: USD $1.306884
≥1 USD $1.306884
≥10 USD $1.232906
≥100 USD $1.163123
≥500 USD $1.097285
≥1000 USD $1.035175
Inventory: 2869
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Tongue Thickness 1.22mm
Width - Outer Edges 0.375 9.53mm
Length - Overall 0.933 23.70mm
Thickness 0.048 1.22mm
Length 23.7mm
Technical
Number of Holes 1
Government Qualified No
Stud Diameter 4.82 mm
Heavy Duty No
Insulated Wire Support No
Stud/Tab Size 10 Stud
Terminal Type Circular
Insulation Non-Insulated
Plating Tin
ELV Compliant
Wire Gauge 8 AWG
Contact Finish Tin
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Brazed Seam, Serrated Termination
Series Solistrand
Published 2005
Packaging Bulk
Physical
Material Copper
Mounting Type Free Hanging (In-Line)
Contact Material Copper
Supply Chain
Factory Lead Time 10 Weeks
