52289 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description CONN RING D-SHAPE 1/0AWG #1/2
PDF
/
Buying Options
Total Price: USD $10.5
Unit Price: USD $10.50396
≥1 USD $10.50396
≥10 USD $9.909388
≥100 USD $9.348489
≥500 USD $8.819323
≥1000 USD $8.320112
Inventory: 1083
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Tongue Thickness 1.85mm
Width - Outer Edges 0.875 22.23mm
Diameter - Inside 17.3736 mm
Length - Overall 2.478 62.94mm
Thickness 0.070 1.78mm
Length 62.9412mm

Technical

Stud Size M12
Number of Holes 1
Stud Diameter 12.7 mm
Heavy Duty No
Insulated Wire Support Yes
Stud/Tab Size 1/2 Stud
Wire Cross Section 60.55 mm2
Terminal Type D-Shaped
Insulation Insulated
Insulation Diameter 0.684 (17.37mm)
Terminal and Terminal Block Type RING TERMINAL
ELV Compliant
Wire Gauge 1/0 AWG
Contact Finish Tin
HTS Code 8536.90.40.00
Color Blue
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Plasti-Grip
Published 2008
Packaging Bulk

Physical

Material - Insulation Poly-Vinyl Chloride (PVC)
Mounting Type Free Hanging (In-Line)
Contact Material Copper

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 23 Weeks
