52266-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 4AWG #5/16 CRIMP
PDF
/
Buying Options
Total Price: USD $2.78
Unit Price: USD $2.7808
≥1 USD $2.7808
≥10 USD $2.47456
≥100 USD $2.196656
≥500 USD $1.805302
≥1000 USD $1.565441
Inventory: 955
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Tongue Thickness 1.22mm
Width - Outer Edges 0.679 17.25mm
Diameter - Inside 11.43 mm
Length - Overall 2.014 51.16mm
Thickness 0.048 1.22mm
Width 17.2mm
Length 51.1556mm
Technical
Stud Size M8
Number of Holes 1
Stud Diameter 8.3312 mm
Heavy Duty No
Insulated Wire Support Yes
Stud/Tab Size 5/16 Stud
Wire Cross Section 26.7 mm2
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.450 (11.43mm)
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 4 AWG
ELV Compliant
Wire Gauge 4 AWG
Voltage - Rated AC 600V
Depth 17.25mm
Orientation Straight
HTS Code 8536.90.40.00
Gender Female
Color Yellow
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Plasti-Grip
Published 2006
Packaging Bulk
Physical
Material - Insulation Poly-Vinyl Chloride (PVC)
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 12 Weeks
