RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 10-12AWG #1/4
PDF
/
Buying Options
Total Price: USD $4.87
Unit Price: USD $4.871411
≥1 USD $4.871411
≥10 USD $4.595666
≥100 USD $4.335533
≥500 USD $4.090127
≥1000 USD $3.858609
Inventory: 2030
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Material Copper
Contact Plating Nickel
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material - Insulation Polytetrafluoroethylene (PTFE)
Technical
Packaging Bulk
Published 2005
Series PIDG, Strato-Therm
Feature Serrated Termination
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Color Black
Gender Female
HTS Code 8536.90.40.00
Orientation Straight
Depth 13.49mm
Voltage - Rated AC 300V
Wire Gauge 10-12 AWG
Wire Gauge (Max) 12 AWG
Wire Gauge (Min) 10 AWG
Wire/Cable Gauge -10 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.102 ~ 0.214 (2.59mm ~ 5.44mm)
Insulation Insulated
Terminal Type Circular
Wire Cross Section 6.64 mm2
Stud/Tab Size 1/4 Stud
Insulated Wire Support Yes
Heavy Duty No
Stud Diameter 6.731 mm
Number of Holes 1
Stud Size M6
Dimensions
Length 32.512mm
Thickness 0.040 1.02mm
Length - Overall 1.280 32.51mm
Diameter - Inside 5.969 mm
Width - Outer Edges 0.531 13.49mm
Tongue Thickness 1.0668mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
