50845-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 10-12AWG #10
PDF
/
Buying Options
Total Price: USD $6.16
Unit Price: USD $6.16
≥1 USD $6.16
≥10 USD $5.3724
≥100 USD $5.231072
≥500 USD $5.089744
≥1000 USD $4.778752
≥3000 USD $4.750522
Inventory: 7566
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Tongue Thickness 1.0668mm
Width - Outer Edges 0.375 9.53mm
Length - Overall 1.083 27.51mm
Thickness 0.039 0.99mm
Length 27.5082mm
Technical
Stud Size M5
Number of Holes 1
Stud Diameter 5 mm
Heavy Duty No
Insulated Wire Support Yes
Stud/Tab Size 10 Stud
Wire Cross Section 6.64 mm2
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.102 ~ 0.214 (2.59mm ~ 5.44mm)
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge -10 AWG
Wire Gauge (Min) 10 AWG
Wire Gauge (Max) 12 AWG
Wire Gauge 10-12 AWG
Voltage - Rated AC 300V
Depth 9.52mm
Orientation Straight
HTS Code 8536.90.40.00
Gender Female
Color Black
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Serrated Termination
Series PIDG, Strato-Therm
Published 2006
Packaging Bulk
Physical
Material - Insulation Polytetrafluoroethylene (PTFE)
Mounting Type Free Hanging (In-Line)
Mount Stud
Contact Plating Nickel
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 4 Weeks
