RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 22-26AWG #2 CRIMP
PDF
/
Buying Options
Total Price: USD $0.9
Unit Price: USD $0.8976
≥1 USD $0.8976
≥10 USD $0.85448
≥100 USD $0.703736
≥500 USD $0.553203
≥1000 USD $0.47417
≥3000 USD $0.465749
Inventory: 15112
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Tongue Thickness 510μm
Material Thickness 508μm
Width - Outer Edges 0.140 3.56mm
Diameter - Inside 787 μm
Length - Overall 0.419 10.64mm
Thickness 0.018 0.46mm
Length 10.6426mm
Technical
Stud Size M2
Number of Holes 1
Government Qualified No
Stud Diameter 2.18 mm
Heavy Duty No
Insulated Wire Support No
Stud/Tab Size 2 Stud
Terminal Type Circular
Insulation Non-Insulated
Sealable No
Wire/Cable Gauge 22 AWG
Body Plating Tin
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 22 AWG
Plating Tin
ELV Compliant
Wire Gauge 22-26 AWG
Contact Finish Tin
Depth 3.55mm
Orientation Straight
Gender Female
Color Yellow
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Brazed Seam, Serrated Termination
Series Solistrand
Published 2007
Packaging Bulk
Physical
Body Material Copper
Material Copper
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 7 Weeks
