42190-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 12-18AWG CRIMP
PDF
/
Inventory: 1136
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Tongue Thickness 457.2μm
Material Thickness 457.2μm
Width - Outer Edges 0.376 9.55mm
Length - Overall 0.720 18.29mm
Thickness 0.018 0.46mm
Length 18.288mm
Technical
Number of Holes 1
Stud Diameter 4.3688 mm
Terminal Gender FEMALE
Heavy Duty No
Insulated Wire Support Yes
Wire Cross Section 3 mm2
Wire/Cable Diameter 5.3 mm
Terminal Type Circular
Insulation Non-Insulated
Insulation Diameter 0.110 ~ 0.210 (2.79mm ~ 5.33mm)
Terminal and Terminal Block Type WIRE TERMINAL
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 18 AWG
Wire/Cable Type Discrete
ELV Compliant
Wire Gauge 12-18 AWG
Contact Finish Tin
Orientation Right Angle
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp, Flag
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Serrated Termination
Published 2004
Packaging Reel
Physical
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 9 Weeks
