41356 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description CONN RING CIRC 10-12AWG #1/4
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.370802
≥1 USD $0.370802
≥200 USD $0.147951
≥500 USD $0.143014
≥1000 USD $0.140572
Inventory: 4837
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Tongue Thickness 1.02mm
Material Thickness 1.016mm
Width - Outer Edges 0.500 12.70mm
Diameter - Inside 3.3 mm
Length - Overall 0.820 20.83mm
Thickness 0.040 1.02mm
Length 20.95mm

Technical

Stud Size M6
Number of Holes 1
Stud Diameter 6.731 mm
Heavy Duty No
Stud/Tab Size 1/4 Stud
Wire Cross Section 6 mm2
Terminal Type Circular
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge (Min) 10 AWG
Wire Gauge (Max) 12 AWG
ELV Compliant
Wire Gauge 10-12 AWG
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Serrated Termination
Published 2004
Packaging Reel

Physical

Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Brass

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 9 Weeks
