40725-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Ring Tongue Terminal 14-18AWG 19.91mm 8.69mm Tin Strip on Reel
PDF
/
Inventory: 6441
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Tongue Thickness 762μm
Material Thickness 760μm
Width - Outer Edges 0.342 8.69mm
Diameter - Inside 1.52 mm
Length - Overall 0.784 19.91mm
Thickness 0.029 0.74mm
Length 19.91mm
Technical
Number of Holes 1
Stud Diameter 4.82 mm
Heavy Duty No
Insulated Wire Support Yes
Stud/Tab Size 10 Stud
Wire Cross Section 2 mm2
Terminal Type Circular
Insulation Non-Insulated
Insulation Diameter 0.100 ~ 0.140 (2.54mm ~ 3.56mm)
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 18 AWG
ELV Compliant
Wire Gauge 14-18 AWG
Contact Finish Tin
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2011
Packaging Reel
Physical
Material Bronze
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Phosphor Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 10 Weeks
