RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 14-18AWG #10
PDF
/
Buying Options
Total Price: USD $0.16
Unit Price: USD $0.1584
≥1 USD $0.1584
≥10 USD $0.132
≥100 USD $0.122848
≥500 USD $0.116512
≥1000 USD $0.110264
≥3000 USD $0.102643
Inventory: 3195
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Material Brass
Contact Plating Unplated
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Tape & Reel (TR)
Published 2004
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
HTS Code 8536.90.40.00
Orientation Straight
Wire Gauge 14-18 AWG
ELV Compliant
Wire Gauge (Max) 18 AWG
Wire Gauge (Min) 14 AWG
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Diameter 3.56 mm
Insulation Non-Insulated
Terminal Type Circular
Wire Cross Section 0.8 mm2
Stud/Tab Size 10 Stud
Insulated Wire Support Yes
Heavy Duty No
Terminal Gender FEMALE
Stud Diameter 5 mm
Number of Holes 1
Dimensions
Length 19.91mm
Plating Thickness 2.54μm
Thickness 0.029 0.74mm
Length - Overall 0.784 19.91mm
Diameter - Inside 1.52 mm
Width - Outer Edges 0.342 8.69mm
Material Thickness 760μm
Tongue Thickness 762μm
Compliance
RoHS Status RoHS Compliant
Lead Free Not Applicable
