RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 14-18AWG #10
PDF
/
Buying Options
Total Price: USD $0.2
Unit Price: USD $0.2024
≥1 USD $0.2024
≥10 USD $0.17248
≥100 USD $0.16016
≥500 USD $0.151888
≥1000 USD $0.143704
≥3000 USD $0.13376
Inventory: 25311
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Tongue Thickness 500μm
Material Thickness 508μm
Width - Outer Edges 0.300 7.62mm
Diameter - Inside 1.65 mm
Length - Overall 0.535 13.59mm
Thickness 0.020 0.51mm
Length 13.716mm
Technical
Number of Holes 1
Stud Diameter 4.82 mm
Heavy Duty No
Stud/Tab Size 10 Stud
Wire Cross Section 2 mm2
Terminal Type Circular
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 14 AWG
ELV Compliant
Wire Gauge 14-18 AWG
Depth 7.62mm
Orientation Straight
HTS Code 8536.90.40.00
Gender Female
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2004
Packaging Tape & Reel (TR)
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 8 Weeks
