36271 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description CONN RING CIRC 10-12AWG #10
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.924
≥1 USD $0.924
≥10 USD $0.86504
≥100 USD $0.83248
≥500 USD $0.82456
≥1000 USD $0.744128
≥3000 USD $0.719981
Inventory: 3911
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 7 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)

Physical

Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Material Copper
Body Material Copper

Technical

Packaging Bulk
Published 1998
Series Solistrand
Feature Brazed Seam, Serrated Termination
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp, Flag
Color Yellow
Gender Female
Orientation Right Angle
Depth 9.53mm
Contact Finish Tin
Wire Gauge 10-12 AWG
ELV Compliant
Plating Tin
Wire Gauge (Max) 12 AWG
Wire Gauge (Min) 10 AWG
Body Plating Tin
Sealable No
Insulation Non-Insulated
Terminal Type Circular
Stud/Tab Size 10 Stud
Insulated Wire Support No
Heavy Duty No
Stud Diameter 5 mm
Government Qualified No
Number of Holes 1

Dimensions

Length 17.83mm
Width 9.53mm
Plating Thickness 2.54μm
Thickness 0.039 0.99mm
Length - Overall 0.702 17.83mm
Diameter - Inside 3.28 mm
Width - Outer Edges 0.375 9.53mm
Material Thickness 990.6μm
Tongue Thickness 990μm

Compliance

Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Not Applicable
