RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 14-16AWG #6 CRIMP
PDF
/
Buying Options
Total Price: USD $0.73
Unit Price: USD $0.7304
≥1 USD $0.7304
≥10 USD $0.69872
≥100 USD $0.523547
≥500 USD $0.452716
≥1000 USD $0.388045
≥3000 USD $0.381154
Inventory: 1376
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Tongue Thickness 1.27mm
Material Thickness 1.27mm
Width - Outer Edges 0.281 7.14mm
Diameter - Inside 6.43 mm
Length - Overall 0.953 24.21mm
Thickness 0.048 1.22mm
Plating Thickness 2.54μm
Length 24.13mm
Technical
Stud Size M3.5
Number of Holes 1
Government Qualified No
Stud Diameter 3.68 mm
Heavy Duty Yes
Insulated Wire Support Yes
Stud/Tab Size 6 Stud
Wire/Cable Diameter 6.35 mm
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.150 ~ 0.250 (3.81mm ~ 6.35mm)
Sealable No
Body Plating Tin
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 14 AWG
Plating Tin
Wire Gauge 14-16 AWG
Voltage - Rated AC 300V
Contact Finish Tin
Depth 7.14mm
Orientation Straight
Gender Female
Color Yellow, Black Stripe
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Heavy Duty, Serrated Termination
Series PIDG
Published 1999
Packaging Bulk
Physical
Body Material Copper
Material - Insulation Polyamide (PA), Nylon
Material Copper
Mounting Type Free Hanging (In-Line)
Mount Stud
Contact Plating Tin
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 26 Weeks
