RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Terminals TERMINAL PIDG HK 16-
PDF
/
Buying Options
Total Price: USD $1.2
Unit Price: USD $1.201304
≥1 USD $1.201304
≥200 USD $0.479209
≥500 USD $0.463454
≥1000 USD $0.455576
Inventory: 4240
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material - Insulation Poly-Vinyl Chloride (PVC)
Technical
Packaging Bulk
Published 1997
Series PIDG
Feature Serrated Termination
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Color Blue
HTS Code 8536.90.40.00
Voltage - Rated AC 300V
Wire Gauge 14-16 AWG
ELV Compliant
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 14 AWG
Insulation Diameter 0.115 ~ 0.170 (2.92mm ~ 4.32mm)
Insulation Insulated
Terminal Type Hook
Wire/Cable Diameter 4.318 mm
Wire Cross Section 2.62 mm2
Stud/Tab Size 10 Stud
Insulated Wire Support Yes
Heavy Duty No
Terminal Gender FEMALE
Stud Diameter 5 mm
Number of Holes 1
Dimensions
Length 21.844mm
Plating Thickness 2.54μm
Thickness 0.031 0.79mm
Length - Overall 0.859 21.82mm
Width - Outer Edges 0.343 8.71mm
Material Thickness 790μm
Tongue Thickness 790μm
Compliance
RoHS Status RoHS Compliant
Lead Free Not Applicable
