RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 14-16AWG #1/4
PDF
/
Buying Options
Total Price: USD $0.68
Unit Price: USD $0.6776
≥1 USD $0.6776
≥10 USD $0.65912
≥100 USD $0.65648
≥500 USD $0.634304
≥1000 USD $0.531784
≥3000 USD $0.498573
Inventory: 7992
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Tongue Thickness 1.22mm
Material Thickness 1.22mm
Width - Outer Edges 0.500 12.70mm
Diameter - Inside 6.4 mm
Length - Overall 1.188 30.18mm
Thickness 0.048 1.22mm
Plating Thickness 2.54μm
Width 12.7mm
Length 30.226mm
Technical
Stud Size M6
Number of Holes 1
Stud Diameter 6.731 mm
Heavy Duty Yes
Stud/Tab Size 1/4 Stud
Wire Cross Section 2.62 mm2
Wire/Cable Diameter 6.35 mm
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.150 ~ 0.250 (3.81mm ~ 6.35mm)
Terminal and Terminal Block Type RING TERMINAL
Sealable No
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 14 AWG
ELV Compliant
Wire Gauge 14-16 AWG
Voltage - Rated AC 600V
Orientation Straight
HTS Code 8536.90.40.00
Color Yellow, Black Stripe
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Heavy Duty, Serrated Termination
Series Plasti-Grip
Published 2004
Packaging Bulk
Physical
Material - Insulation Poly-Vinyl Chloride (PVC)
Mounting Type Free Hanging (In-Line)
Mount Stud
Contact Plating Tin
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 7 Weeks
