35151 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description CONN RING CIRC 10-12AWG #1/2
PDF
/
Buying Options
Total Price: USD $0.82
Unit Price: USD $0.8184
≥1 USD $0.8184
≥10 USD $0.77792
≥100 USD $0.582472
≥500 USD $0.503668
≥1000 USD $0.431719
≥3000 USD $0.424054
Inventory: 1080
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)

Physical

Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material Copper
Material - Insulation Polyamide (PA), Nylon
Body Material Copper

Technical

Packaging Bulk
Published 2007
Series PIDG
Feature Serrated Termination
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Color Yellow
Gender Female
Orientation Straight
Depth 19.05mm
Contact Finish Tin
Voltage - Rated AC 300V
Wire Gauge 10-12 AWG
ELV Compliant
Plating Tin
Wire Gauge (Max) 12 AWG
Wire Gauge (Min) 10 AWG
Body Plating Tin
Sealable No
Insulation Diameter 0.150 ~ 0.250 (3.81mm ~ 6.35mm)
Insulation Insulated
Thread Size M12
Terminal Type Circular
Wire/Cable Diameter 6.35 mm
Stud/Tab Size 1/2 Stud
Insulated Wire Support Yes
Heavy Duty No
Stud Diameter 13.08 mm
Government Qualified No
Number of Holes 1
Stud Size M12

Dimensions

Length 40.386mm
Width 19.1mm
Plating Thickness 2.54μm
Thickness 0.039 0.99mm
Length - Overall 1.594 40.49mm
Diameter - Inside 6.43 mm
Width - Outer Edges 0.750 19.05mm
Material Thickness 1.016mm
Tongue Thickness 1.02mm

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free
