RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 10-12AWG #5/16
PDF
/
Buying Options
Total Price: USD $3.57
Unit Price: USD $3.5728
≥1 USD $3.5728
Inventory: 66
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Contact Material Copper
Contact Plating Tin
Mount Stud
Mounting Type Free Hanging (In-Line)
Material - Insulation Polyamide (PA), Nylon
Technical
Packaging Bulk
Published 2007
Series PIDG
Feature Serrated Termination
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Color Yellow
Gender Female
HTS Code 8536.90.40.00
Orientation Straight
Depth 13.49mm
Voltage - Rated AC 300V
Wire Gauge 10-12 AWG
ELV Compliant
Wire Gauge (Max) 12 AWG
Wire Gauge (Min) 10 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.150 ~ 0.250 (3.81mm ~ 6.35mm)
Insulation Insulated
Terminal Type Circular
Wire/Cable Diameter 6.35 mm
Stud/Tab Size 5/16 Stud
Insulated Wire Support Yes
Heavy Duty No
Stud Diameter 8.3312 mm
Number of Holes 1
Stud Size M8
Dimensions
Length 33.58mm
Width 13.5mm
Plating Thickness 2.54μm
Thickness 0.040 1.02mm
Length - Overall 1.322 33.58mm
Diameter - Inside 6.4 mm
Width - Outer Edges 0.531 13.49mm
Material Thickness 1.016mm
Tongue Thickness 1.02mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
