35108 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description CONN RING CIRC 10-12AWG #8 CRIMP
PDF
/
Buying Options
Total Price: USD $0.57
Unit Price: USD $0.565121
≥1 USD $0.565121
≥10 USD $0.469626
≥100 USD $0.422532
Inventory: 74
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No

Dimensions

Tongue Thickness 1.02mm
Material Thickness 1.016mm
Width - Outer Edges 0.375 9.53mm
Diameter - Inside 6.4 mm
Length - Overall 1.083 27.51mm
Thickness 0.040 1.02mm
Plating Thickness 2.54μm
Length 27.432mm

Technical

Stud Size M4
Number of Holes 1
Government Qualified Yes
Stud Diameter 4.34 mm
Heavy Duty No
Insulated Wire Support Yes
Stud/Tab Size 8 Stud
Wire/Cable Diameter 6.35 mm
Terminal Type Circular
Thread Size M4
Insulation Insulated
Insulation Diameter 0.150 ~ 0.250 (3.81mm ~ 6.35mm)
Sealable No
Body Plating Tin
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 10 AWG
Plating Tin
Wire Gauge 10-12 AWG
Voltage - Rated AC 300V
Contact Finish Tin
Depth 9.53mm
Orientation Straight
Gender Female
Color Yellow
Max Operating Temperature 105°C
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Serrated Termination
Series PIDG
Published 2008
Packaging Bulk

Physical

Body Material Copper
Material - Insulation Polyamide (PA), Nylon
Material Copper
Mounting Type Free Hanging (In-Line)
Mount Stud
Contact Plating Tin
Contact Material Copper

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 4 Weeks
