RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 10-12AWG #1/4
PDF
/
Buying Options
Total Price: USD $0.36
Unit Price: USD $0.356977
≥1 USD $0.356977
≥10 USD $0.33677
≥100 USD $0.317708
≥500 USD $0.29972
≥1000 USD $0.28276
Inventory: 5543
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 1997
Series Budget
Feature Serrated Termination
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Color Yellow
Gender Female
HTS Code 8536.90.40.00
Orientation Straight
Contact Finish Tin
Wire Gauge 10-12 AWG
ELV Compliant
Wire Gauge (Max) 12 AWG
Wire Gauge (Min) 10 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Circular
Wire Cross Section 6 mm2
Stud/Tab Size 1/4 Stud
Heavy Duty No
Stud Diameter 6.731 mm
Number of Holes 1
Stud Size M6
Dimensions
Length 21.97mm
Width 12.7mm
Plating Thickness 2.54μm
Thickness 0.039 0.99mm
Length - Overall 0.865 21.97mm
Diameter - Inside 3.45 mm
Width - Outer Edges 0.500 12.70mm
Material Thickness 990.6μm
Tongue Thickness 990μm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Not Applicable
