34833 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description CONN RING CIRC 10-12AWG #3/8
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Not Applicable
RoHS Status RoHS Compliant
REACH SVHC No SVHC

Dimensions

Tongue Thickness 990μm
Material Thickness 990.6μm
Width - Outer Edges 0.750 19.05mm
Diameter - Inside 3.4 mm
Length - Overall 1.271 32.28mm
Thickness 0.039 0.99mm
Plating Thickness 2.54μm
Length 32.258mm

Technical

Number of Holes 1
Stud Diameter 9.906 mm
Heavy Duty No
Stud/Tab Size 3/8 Stud
Wire Cross Section 6.64 mm2
Terminal Type Circular
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge (Min) 10 AWG
Wire Gauge (Max) 12 AWG
ELV Compliant
Wire Gauge 10-12 AWG
Contact Finish Tin
Orientation Straight
HTS Code 8536.90.40.00
Gender Female
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Serrated Termination
Series Budget
Published 1997
Packaging Bulk

Physical

Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 12 Weeks
