RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 16-22AWG #10
PDF
/
Buying Options
Total Price: USD $0.36
Unit Price: USD $0.3608
≥1 USD $0.3608
≥10 USD $0.32472
≥100 USD $0.270424
≥500 USD $0.201458
≥1000 USD $0.179819
≥3000 USD $0.167332
Inventory: 38714
Minimum: 1
-
+
Technical Details
Technical
Min Operating Temperature -25°C
Color Red
Gender Female
HTS Code 8536.90.40.00
Orientation Straight
Depth 7.92mm
Voltage - Rated AC 600V
Wire Gauge 16-22 AWG
ELV Compliant
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 16 AWG
Wire/Cable Gauge 16 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.105 ~ 0.140 (2.67mm ~ 3.56mm)
Insulation Insulated
Terminal Type Circular
Wire/Cable Diameter 3.56 mm
Stud/Tab Size 10 Stud
Insulated Wire Support Yes
Heavy Duty No
Stud Diameter 4.82 mm
Number of Holes 1
Stud Size M5
Max Operating Temperature 90°C
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Serrated Termination
Series Plasti-Grip
Published 2006
Packaging Bulk
Dimensions
Length 21.74mm
Plating Thickness 2.54μm
Thickness 0.031 0.79mm
Length - Overall 0.856 21.74mm
Diameter - Inside 3.68 mm
Width - Outer Edges 0.312 7.92mm
Material Thickness 787.4μm
Tongue Thickness 790μm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
Physical
Material - Insulation Poly-Vinyl Chloride (PVC)
Mounting Type Free Hanging (In-Line)
Mount Stud
Contact Plating Tin
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 4 Weeks
