RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 16-22AWG #4 CRIMP
PDF
/
Buying Options
Total Price: USD $6.67
Unit Price: USD $6.6704
≥1 USD $6.6704
Inventory: 92
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material Copper
Material - Insulation Poly-Vinyl Chloride (PVC)
Body Material Copper
Technical
Packaging Bulk
Published 2009
Series Plasti-Grip
Feature Serrated Termination
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Color Red
Gender Female
Orientation Straight
Depth 5.54mm
Contact Finish Tin
Voltage - Rated AC 600V
Wire Gauge 16-22 AWG
Plating Tin
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 16 AWG
Body Plating Tin
Sealable No
Insulation Diameter 0.105 ~ 0.140 (2.67mm ~ 3.56mm)
Insulation Insulated
Thread Size M2.5
Terminal Type Circular
Wire/Cable Diameter 3.56 mm
Stud/Tab Size 4 Stud
Insulated Wire Support Yes
Heavy Duty No
Stud Diameter 3.0226 mm
Government Qualified No
Number of Holes 1
Stud Size M2.5
Dimensions
Length 17.37mm
Thickness 0.031 0.79mm
Length - Overall 0.684 17.37mm
Width - Outer Edges 0.218 5.54mm
Tongue Thickness 840μm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
