RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 16-22AWG #3/8
PDF
/
Buying Options
Total Price: USD $0.32
Unit Price: USD $0.3168
≥1 USD $0.3168
≥10 USD $0.28336
≥100 USD $0.281952
≥500 USD $0.276144
≥1000 USD $0.236104
≥3000 USD $0.212467
Inventory: 9023
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Tongue Thickness 790μm
Material Thickness 840μm
Width - Outer Edges 0.531 13.49mm
Diameter - Inside 1.55 mm
Length - Overall 0.995 25.27mm
Thickness 0.031 0.79mm
Width 13.5mm
Length 25.27mm
Technical
Stud Size M10
Number of Holes 1
Government Qualified Yes
Stud Diameter 9.906 mm
Heavy Duty No
Stud/Tab Size 3/8 Stud
Terminal Type Circular
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 22 AWG
ELV Compliant
Wire Gauge 16-22 AWG
Depth 13.49mm
Orientation Straight
HTS Code 8536.90.40.00
Gender Female
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Brazed Seam, Serrated Termination
Series Solistrand
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Stud
Contact Plating Tin
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 4 Weeks
