330968 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description Terminals TERMINAL SOLIS R HR 1/0 5/16 20bend
PDF
/
Buying Options
Total Price: USD $1.02
Unit Price: USD $1.022749
≥1 USD $1.022749
Inventory: 6969
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Not Applicable
RoHS Status RoHS Compliant

Dimensions

Tongue Thickness 1.016mm
Material Thickness 2.41mm
Width - Outer Edges 0.500 12.70mm
Length - Overall 0.949 24.10mm
Thickness 0.091 2.31mm
Length 24.1mm

Technical

Stud Size M6
Number of Holes 1
Stud Diameter 6.731 mm
Heavy Duty Yes
Insulated Wire Support No
Stud/Tab Size 1/4 Stud
Terminal Type Circular
Insulation Non-Insulated
Insulation Diameter 9.779 mm
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 8 AWG
Plating Tin
ELV Compliant
Wire Gauge 8 AWG
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Brazed Seam, Heavy Duty, Serrated Termination
Series Solistrand
Published 1997
Packaging Bulk

Physical

Mounting Type Free Hanging (In-Line)
Contact Material Copper

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 14 Weeks
